LQH32DN390K23L

Murata Electronics
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description LQH32 Nonstandard 0.126Lx0.098W 3.20mmx2.50mm 39muH
PDF
/
Buying Options
Total Price: USD $0.25
Unit Price: USD $0.249902
≥1 USD $0.249902
≥10 USD $0.235757
≥100 USD $0.222416
≥500 USD $0.209829
≥1000 USD $0.197943
Inventory: 1113
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height Seated (Max) 0.087 2.20mm
Height 2mm

Technical

Rated Current-Max 0.2A
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 16MHz
DC Resistance (DCR) 1.56Ohm Max
Test Frequency 1MHz
Inductance 39μH
Case Code (Imperial) 1210
Case Code (Metric) 3225
Current Rating 200mA
Number of Functions 1
Shielding NO
HTS Code 8504.50.80.00
Resistance 1.56Ohm
Type Wirewound
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±10%
Size / Dimension 0.126Lx0.098W 3.20mmx2.50mm
Series LQH32
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Weight 15.989131mg
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 8 Weeks
