LQH32CH4R7M33L

Murata Electronics
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description LQH32 Nonstandard 0.126Lx0.098W 3.20mmx2.50mm 4.7muH
PDF
/
Inventory: 1244
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Height Seated (Max) 0.087 2.20mm
Height 2mm

Technical

Special Feature DCR IS MEASURED AT 30% TOLERANCE
Inductance Frequency - Test 1MHz
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 43MHz
Max DC Current 650mA
DC Resistance (DCR) 150mOhm
Test Frequency 1MHz
Inductance 4.7μH
Reference Standard AEC-Q200
Depth 2.7mm
Number of Functions 1
Shielding Unshielded
HTS Code 8504.50.80.00
Terminal Finish Tin/Copper (Sn/Cu)
Type Wirewound
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e2
Tolerance ±20%
Size / Dimension 0.126Lx0.098W 3.20mmx2.50mm
Series LQH32
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Weight 59.987591mg
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case Nonstandard
Mounting Type Surface Mount

Supply Chain

Lifecycle Status IN PRODUCTION (Last Updated: 3 weeks ago)
