LQH31MN5R6K01L
RoHS
/
Package 1206
Category Inductors, Coils, Chokes / Fixed Inductors
Description
1206 5.6muH 10%
PDF
/
Inventory: 2101
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case 1206
Surface Mount YES
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Tolerance 10%
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -25°C
HTS Code 8504.50.80.00
Shielding Unshielded
Number of Functions 1
Inductance 5.6 μH
Test Frequency 1MHz
Max DC Current 115mA
Frequency - Self Resonant 28MHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Quality Factor-Min (at L-nom) 35
Inductor Type GENERAL PURPOSE INDUCTOR
Q Factor 35
DC Resistance (DCR) - Parallel 1.8Ohm
Inductance-Nom (L) 5.6 μH
Special Feature Q MEASURED AT 8 MHZ
Dimensions
Height 1.8mm
Length 3.2mm
Width 1.6mm
Compliance
RoHS Status Non-RoHS Compliant
