DFEH12060D-220M=P3
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
DFEH12060D Nonstandard 0.512Lx0.496W 13.00mmx12.60mm 22muH
PDF
/
Buying Options
Total Price: USD $2.21
Unit Price: USD $2.206156
≥1 USD $2.206156
≥10 USD $2.081285
≥100 USD $1.963469
≥500 USD $1.852332
≥1000 USD $1.747477
Inventory: 1147
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.236 6.00mm
Technical
Rated Current-Max 6A
Current - Saturation 6.5A
Inductor Type GENERAL PURPOSE INDUCTOR
Inductance Frequency - Test 100MHz
Terminal Placement DUAL ENDED
DC Resistance (DCR) 35mOhm Max
Test Frequency 100MHz
Inductance 22μH
Current Rating 6A
Number of Functions 1
Shielding YES
HTS Code 8504.50.80.00
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Tolerance ±20%
Size / Dimension 0.512Lx0.496W 13.00mmx12.60mm
Series DFEH12060D
Packaging Tape & Reel (TR)
Operating Temperature -40°C~155°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Iron Powder
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status NRND (Last Updated: 1 month ago)
