DFEG12060D-8R2M=P3
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
DFEG12060D Nonstandard 0.512Lx0.496W 13.00mmx12.60mm 8.2muH
PDF
/
Buying Options
Total Price: USD $2.06
Unit Price: USD $2.057239
≥1 USD $2.057239
≥10 USD $1.940782
≥100 USD $1.830937
≥500 USD $1.727302
≥1000 USD $1.629523
Inventory: 1155
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status NRND (Last Updated: 4 weeks ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Material - Core Iron Powder
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series DFEG12060D
Size / Dimension 0.512Lx0.496W 13.00mmx12.60mm
Tolerance ±20%
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
HTS Code 8504.50.80.00
Shielding YES
Number of Functions 1
Current Rating 8A
Inductance 8.2μH
Test Frequency 100MHz
DC Resistance (DCR) 17mOhm Max
Terminal Placement DUAL ENDED
Inductance Frequency - Test 100kHz
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 11A
Rated Current-Max 8A
Dimensions
Height Seated (Max) 0.236 6.00mm
Compliance
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
