DFE322512F-3R3M=P2
RoHS
RoHS compliant
RoHS compliantPackage 1210 (3225 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
DFE322512F 1210 (3225Metric) 0.126Lx0.098W 3.20mmx2.50mm 3.3muH
PDF
/
Buying Options
Total Price: USD $0.49
Unit Price: USD $0.486526
≥1 USD $0.486526
≥10 USD $0.458989
≥100 USD $0.433001
≥500 USD $0.408492
≥1000 USD $0.385372
Inventory: 4993
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.047 1.20mm
Technical
Inductance Tolerance 20%
Rated Current-Max 2A
Current - Saturation 2.6A
Inductance Frequency - Test 1MHz
Terminal Placement DUAL ENDED
DC Resistance (DCR) 108mOhm Max
Test Frequency 1MHz
Inductance 3.3μH
Number of Functions 1
Shielding Shielded
Current Rating (Amps) 2A
Type Wirewound
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.126Lx0.098W 3.20mmx2.50mm
Series DFE322512F
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Metal
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case 1210 (3225 Metric)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 12 Weeks
