DFE201612PD-1R5M=P2
RoHS
RoHS compliant
RoHS compliantPackage 0806 (2016 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
DFE201612P 0806 (2016Metric) 0.079Lx0.063W 2.00mmx1.60mm 1.5muH
PDF
/
Buying Options
Total Price: USD $0.37
Unit Price: USD $0.374381
≥1 USD $0.374381
≥10 USD $0.35319
≥100 USD $0.333203
≥500 USD $0.314337
≥1000 USD $0.296553
Inventory: 1124
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Surface Mount
Package / Case 0806 (2016 Metric)
Surface Mount YES
Terminal Shape WRAPAROUND
Material - Core Metal
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series DFE201612P
Size / Dimension 0.079Lx0.063W 2.00mmx1.60mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Type Wirewound
Current Rating (Amps) 1.7A
Shielding Shielded
Number of Functions 1
Inductance 1.5μH
Test Frequency 1MHz
DC Resistance (DCR) 98mOhm Max
Terminal Placement DUAL ENDED
Inductance Frequency - Test 1MHz
Current - Saturation 2A
Rated Current-Max 1.7A
Dimensions
Height Seated (Max) 0.047 1.20mm
Compliance
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
