DEM8045Z-8R2M=P3
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Wirewound Active WRAPAROUND Fixed Inductor -40C~105C 100kHz 33.6mOhm Max 8.2muH
PDF
/
Buying Options
Total Price: USD $0.76
Unit Price: USD $0.7568
≥1 USD $0.7568
≥10 USD $0.64328
≥100 USD $0.585024
≥500 USD $0.55
≥1000 USD $0.456368
≥3000 USD $0.421274
Inventory: 1000
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.177 4.50mm
Technical
Rated Current-Max 4.5A
Current - Saturation 4.8A
Inductance Frequency - Test 100kHz
Terminal Placement DUAL ENDED
DC Resistance (DCR) 33.6mOhm Max
Test Frequency 0.1MHz
Inductance 8.2μH
Number of Functions 1
Shielding Shielded
Current Rating (Amps) 4.5A
Type Wirewound
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.315Lx0.315W 8.00mmx8.00mm
Series DEM8045C
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case Nonstandard
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 13 Weeks
