SBCP-80HY680H
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical Cylinder
Category Inductors, Coils, Chokes / Fixed Inductors
Description
SBCP Radial Vertical Cylinder 0.374Dia 9.50mm 68muH
PDF
/
Buying Options
Total Price: USD $1.88
Unit Price: USD $1.875655
≥1 USD $1.875655
≥10 USD $1.769483
≥100 USD $1.669325
≥500 USD $1.574834
≥1000 USD $1.485692
Inventory: 1168
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.433 11.00mm
Technical
Inductance Tolerance 10%
Rated Current-Max 1.7A
Current - Saturation 1.8A
Inductance Frequency - Test 10kHz
DC Resistance (DCR) 160mOhm Max
Inductance 68μH
Lead Diameter 0.6 mm
Lead Spacing 5mm
Lead Length 3.5mm
Construction Cylindrical
Shielding Unshielded
Packing Method TR
Current Rating (Amps) 1.7A
HTS Code 8504.50.80.00
Type Wirewound
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Tolerance ±10%
Size / Dimension 0.374Dia 9.50mm
Series SBCP
Published 2016
Packaging Tape & Reel (TR)
Operating Temperature -20°C~105°C
Physical
Material - Core Ferrite
Package / Case Radial, Vertical Cylinder
Mounting Type Through Hole
Supply Chain
Factory Lead Time 29 Weeks
