1530B566
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
1530 Axial 0.150Diax0.250L 3.81mmx6.35mm 5.6muH
PDF
/
Buying Options
Total Price: USD $8.6
Unit Price: USD $8.599495
≥1 USD $8.599495
≥200 USD $3.431921
≥500 USD $3.317698
≥1000 USD $3.259931
Inventory: 5371
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Axial
Terminal Shape PRINTED WIRING PIN
Weight 99.999994g
Material - Core Iron
Shape/Size Description TUBULAR PACKAGE
Technical
Packaging Bulk
Published 2000
Series 1530
Size / Dimension 0.150Diax0.250L 3.81mmx6.35mm
Tolerance ±10%
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
ECCN Code EAR99
Type Wirewound
HTS Code 8504.50.80.00
Shielding NO
Number of Functions 1
Construction Varnish
Current Rating 637mA
Inductance 5.6μH
Test Frequency 7.9MHz
DC Resistance (DCR) 492mOhm Max
Max DC Current 637mA
Inductor Application RF INDUCTOR
Q @ Freq 41 @ 7.9MHz
Quality Factor-Min (at L-nom) 41
Self Resonant Frequency 49MHz
Dimensions
Diameter 3.81mm
Compliance
RoHS Status RoHS Compliant
