SMRF3013-390K
RoHS
/
Package 3013
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR Non-RoHS Compliant WRAPAROUND DUAL ENDED fixed air core inductor 125C 365MHz 300mOhm 390nH
PDF
/
Inventory: 3274
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Self Resonant Frequency 365MHz
Inductance-Nom (L) 0.39 μH
DC Resistance (DCR) - Parallel 300mOhm
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 30
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Max DC Current 821mA
Test Frequency 25MHz
Inductance 390 nH
Operating Temperature (Min) -55°C
Operating Temperature (Max) 125°C
Number of Functions 1
Shielding Unshielded
HTS Code 8504.50.80.00
Terminal Finish Tin/Lead (Sn/Pb)
Resistance 300mOhm
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Pbfree Code no
JESD-609 Code e0
Tolerance 5%
Physical
Core Material PHENOLIC
Shape/Size Description RECTANGULAR PACKAGE
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case 3013
