B82559A4222A20
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
RoHS Compliant Tape & Reel (TR) Ferrite Surface Mount fixed air core inductor 150C 2MHz 1.2mOhm 2.2muH
PDF
/
Inventory: 3436
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 21.0058mm
Length 21.4884mm
Height Seated (Max) 12.192mm
Height 12.2mm
Technical
DC Resistance (DCR) - Parallel 1.2mOhm
Current - Saturation 43A
Frequency - Self Resonant 2MHz
Max DC Current 43A
Test Frequency 100kHz
Inductance 2.2 μH
Depth 21mm
Shielding Shielded
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 150°C
Tolerance 10%
Packaging Tape & Reel (TR)
Physical
Material - Core Ferrite
Number of Pins 20
Package / Case Nonstandard
Mount Surface Mount
