B82477P4104M
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR RoHS Compliant WRAPAROUND DUAL ENDED Fixed Inductor 150C 100kHz 138mOhm 100muH
PDF
/
Inventory: 1168
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 12.4968mm
Length 12.4968mm
Height Seated (Max) 8.509mm
Height 8.5mm
Technical
Inductance-Nom (L) 100 μH
DC Resistance (DCR) - Parallel 138mOhm
Case/Size Code 4949
Current - Saturation 1.95A
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Max DC Current 1.87A
Test Frequency 100kHz
Inductance 100 μH
Operating Temperature (Min) -55°C
Operating Temperature (Max) 150°C
Reference Standard AEC-Q200
Current Rating 1.87A
Construction Rectangular
Depth 12.5mm
Number of Functions 1
Shielding Shielded
Packing Method TR, Blister, 13 Inch
HTS Code 8504.50.80.00
Composition Wirewound
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
ECCN Code EAR99
Number of Terminations 2
Pbfree Code yes
JESD-609 Code e3
Tolerance 20%
Packaging Cut Tape (CT)
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mount Surface Mount
