B82472P6105M

EPCOS
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR RoHS Compliant WRAPAROUND DUAL ENDED fixed air core inductor 150C 100kHz 3.85Ohm 1mH
PDF
/
Inventory: 3993
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Plating Tin
Mount Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE

Technical

Packaging Digi-Reel?
Tolerance 20%
JESD-609 Code e3
Pbfree Code yes
Number of Terminations 2
ECCN Code EAR99
Composition Wirewound
HTS Code 8504.50.80.00
Packing Method TR, Blister, 13 Inch
Shielding Shielded
Number of Functions 1
Depth 7.5mm
Current Rating 200mA
Military Standard Not
Reference Standard AEC-Q200
Operating Temperature (Max) 150°C
Operating Temperature (Min) -55°C
Inductance 1 mH
Test Frequency 100kHz
Max DC Current 200mA
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 150mA
Case/Size Code 2929
DC Resistance (DCR) - Parallel 3.85Ohm
Inductance-Nom (L) 1000 μH
DC Current 200mA

Dimensions

Height 4.5mm
Height Seated (Max) 4.4958mm
Length 7.5mm
Width 7.2898mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
