SDE6603-102M
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
SDE6603 Nonstandard 0.260Lx0.175W 6.60mmx4.45mm 1mH
PDF
/
Inventory: 8729
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Number of Pins 2
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -25°C~105°C
Packaging Cut Tape (CT)
Published 2010
Series SDE6603
Size / Dimension 0.260Lx0.175W 6.60mmx4.45mm
Tolerance ±20%
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
Terminal Finish Silver/Nickel/Gold (Ag/Ni/Au)
HTS Code 8504.50.80.00
Packing Method TR, 13 Inch
Shielding NO
Number of Functions 1
Depth 4.45mm
Current Rating 70mA
Military Standard Not
Inductance 1mH
Test Frequency 100kHz
DC Resistance (DCR) 13.8Ohm Max
Max DC Current 70mA
Frequency - Self Resonant 2MHz
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Current - Saturation 100mA
Inductance Tolerance 20%
DC Current 70mA
RMS Current (Irms) 70mA
Dimensions
Height 2.92mm
Height Seated (Max) 0.115 2.92mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
