B82472G4103M
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR RoHS Compliant Lead Free ONE SURFACE fixed air core inductor 125C 100kHz 80mOhm 10muH
PDF
/
Buying Options
Total Price: USD $0.89
Unit Price: USD $0.891342
≥1 USD $0.891342
≥10 USD $0.840885
≥100 USD $0.793295
≥500 USD $0.748391
≥1000 USD $0.706026
Inventory: 998
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Package / Case Nonstandard
Terminal Shape ONE SURFACE
Weight 1.500002g
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Packaging Tape & Reel (TR)
Tolerance 20%
JESD-609 Code e3
Pbfree Code yes
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Composition Wirewound
HTS Code 8504.50.80.00
Packing Method TR, Blister, 13 Inch
Shielding Shielded
Number of Functions 1
Depth 7.5mm
Construction Rectangular
Current Rating 1.7A
Military Standard Not
Inductance 10 μH
Test Frequency 100kHz
Max DC Current 1.7A
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 1.34A
Case/Size Code 2929
DC Resistance (DCR) - Parallel 80mOhm
Inductance-Nom (L) 10 μH
DC Current 1.7A
Dimensions
Height 3.3mm
Height Seated (Max) 3.5052mm
Length 7.3mm
Width 7.0104mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
