B82462A4224K
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR RoHS Compliant WRAPAROUND DUAL ENDED Fixed Inductor 150C 6MHz 2.72Ohm 220muH
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.070257
≥1 USD $1.070257
≥10 USD $1.009675
≥100 USD $0.952523
≥500 USD $0.898608
≥1000 USD $0.847746
Inventory: 934
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Weight 200.005886mg
Material - Core Ferrite
Shape/Size Description CYLINDRICAL PACKAGE
Technical
Packaging Bulk
Tolerance 10%
JESD-609 Code e3
Pbfree Code yes
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin (Sn) - with Silver (Ag) barrier
Max Operating Temperature 150°C
Composition Wirewound
HTS Code 8504.50.80.00
Shielding Unshielded
Number of Functions 1
Depth 6mm
Current Rating 240mA
Military Standard Not
Inductance 220 μH
Test Frequency 100kHz
Max DC Current 240mA
Frequency - Self Resonant 6MHz
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 400mA
DC Resistance (DCR) - Parallel 2.72Ohm
Inductance-Nom (L) 220 μH
DC Current 240mA
Dimensions
Height 3mm
Height Seated (Max) 2.9972mm
Length 6mm
Width 5.9944mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
