SDH3812-680-R
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
RoHS Compliant Wirewound Obsolete 2007 fixed air core inductor -40C~125C 100kHz 2.4Ohm Max 68muH
PDF
/
Inventory: 3547
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Weight 453.59237mg
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2007
Series SDH3812
Size / Dimension 0.150Lx0.150W 3.80mmx3.80mm
Tolerance ±20%
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 310mA
Shielding Shielded
Current Rating 310mA
Inductance 68μH
Test Frequency 100kHz
DC Resistance (DCR) 2.4Ohm Max
Max DC Current 340mA
Inductance Frequency - Test 100kHz
Current - Saturation 340mA
Dimensions
Height 1.2mm
Height Seated (Max) 0.047 1.20mm
Length 3.7846mm
Width 3.7846mm
Compliance
RoHS Status RoHS Compliant
