SD52-100-R
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
SD52 Nonstandard 0.205Lx0.205W 5.20mmx5.20mm 10muH
PDF
/
Inventory: 7227
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Width 5.2mm
Length 5.2mm
Height Seated (Max) 0.079 2.00mm
Height 2mm
Technical
RMS Current (Irms) 1.11A
DC Current 1.11A
Inductance Tolerance 20%
Current - Saturation 1.11A
Inductance Frequency - Test 100kHz
Max DC Current 1.11A
DC Resistance (DCR) 121.5mOhm
Test Frequency 100kHz
Inductance 10μH
Military Standard Not
Current Rating 1.11A
Depth 5.2mm
Shielding Shielded
Current Rating (Amps) 1.11A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.205Lx0.205W 5.20mmx5.20mm
Series SD52
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Weight 907.18474mg
Number of Pins 2
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
