SD3114-2R2-R
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
RoHS Compliant Wirewound Active Lead Free fixed air core inductor -40C~125C 100kHz 110mOhm 2.2muH
PDF
/
Buying Options
Total Price: USD $1.54
Unit Price: USD $1.537717
≥1 USD $1.537717
≥10 USD $1.473326
≥100 USD $1.423516
≥500 USD $1.363382
≥1000 USD $1.315488
Inventory: 4102
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 3.0988mm
Length 3.0988mm
Height Seated (Max) 0.055 1.40mm
Height 1.4mm
Technical
DC Current 1.17A
Current - Saturation 1.74A
Inductance Frequency - Test 100kHz
Max DC Current 1.74A
DC Resistance (DCR) 110mOhm
Test Frequency 100kHz
Inductance 2.2μH
Military Standard Not
Current Rating 1.17A
Depth 3.1mm
Shielding Shielded
Current Rating (Amps) 1.17A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Resistance 110mOhm
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±30%
Size / Dimension 0.122Lx0.122W 3.10mmx3.10mm
Series SD3114
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Weight 453.59237mg
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
