SD18-2R2-R
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
SD Nonstandard 0.205Lx0.205W 5.20mmx5.20mm 2.2muH
PDF
/
Buying Options
Total Price: USD $2.25
Unit Price: USD $2.2528
≥1 USD $2.2528
≥10 USD $1.91224
≥100 USD $1.762464
≥500 USD $1.575024
≥1000 USD $1.312432
≥3000 USD $1.274944
Inventory: 1114
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Number of Pins 2
Weight 907.18474mg
Material - Core Ferrite
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2007
Series SD
Size / Dimension 0.205Lx0.205W 5.20mmx5.20mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Resistance 39.8mOhm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 2.55A
Shielding Shielded
Depth 5.2mm
Current Rating 2.55A
Military Standard Not
Inductance 2.2μH
Test Frequency 100kHz
DC Resistance (DCR) 39.8mOhm
Max DC Current 2.16A
Inductance Frequency - Test 100kHz
Current - Saturation 2.16A
Inductance Tolerance 20%
DC Current 2.55A
RMS Current (Irms) 2.55A
Dimensions
Height 1.8mm
Height Seated (Max) 0.071 1.80mm
Length 5.2mm
Width 5.2mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
