LDS0705-R82M-R
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Inductor Power Shielded Drum Core 820nH 20% 100KHz Ferrite 7.68A 4mOhm DCR T/R
PDF
/
Inventory: 9494
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Dimensions
Height Seated (Max) 0.197 5.00mm
Technical
Current - Saturation 8.57A
Inductance Frequency - Test 100kHz
DC Resistance (DCR) 4mOhm
Inductance 820nH
Shielding Shielded
Current Rating (Amps) 7.68A
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Tolerance ±20%
Size / Dimension 0.307Lx0.276W 7.80mmx7.00mm
Series LDS0705
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Package / Case Nonstandard
Mounting Type Surface Mount
