HCMA1104-100-R
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
HCMA1104 Nonstandard 0.437Lx0.394W 11.10mmx10.00mm 10muH
PDF
/
Buying Options
Total Price: USD $1.45
Unit Price: USD $1.452
≥1 USD $1.452
≥10 USD $1.23112
≥100 USD $1.11936
≥500 USD $1.052128
≥1000 USD $0.873136
≥3000 USD $0.805939
Inventory: 859
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status RoHS Compliant
Dimensions
Width 10.0076mm
Length 11.0998mm
Height Seated (Max) 0.157 4.00mm
Technical
Current - Saturation 8.5A
Inductance Frequency - Test 100kHz
DC Resistance (DCR) 30mOhm Max
Test Frequency 100kHz
Inductance 10μH
Current Rating 7.5A
Shielding Shielded
Current Rating (Amps) 7.5A
Composition Wirewound
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.437Lx0.394W 11.10mmx10.00mm
Series HCMA1104
Published 2014
Packaging Cut Tape (CT)
Operating Temperature -55°C~125°C
Physical
Material - Core Iron Powder
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
