HCM1A1707V2-150-R
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
IND POWER 15.0UH 11.0A 2 PAD SMT
PDF
/
Buying Options
Total Price: USD $3.7
Unit Price: USD $3.696
≥1 USD $3.696
≥10 USD $3.08968
≥100 USD $2.820928
≥500 USD $2.417888
≥1000 USD $2.216368
Inventory: 220
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mounting Type Surface Mount
Package / Case Nonstandard
Material - Core Iron Powder
Technical
Operating Temperature -55°C~155°C
Packaging Tape & Reel (TR)
Series HCM1AV2
Size / Dimension 0.675Lx0.675W 17.15mmx17.15mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Current Rating (Amps) 11.8A
Shielding Shielded
Inductance 15μH
DC Resistance (DCR) 15.5mOhm Max
Frequency - Self Resonant 5MHz
Inductance Frequency - Test 100kHz
Current - Saturation 11A
Dimensions
Height Seated (Max) 0.276 7.00mm
Compliance
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
