RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description RoHS Compliant Wirewound Active 2014 fixed air core inductor -55C~125C 100kHz 2.5mOhm Max 2.2muH
PDF
/
Inventory: 9101
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 16.8402mm
Length 17.1958mm
Height Seated (Max) 0.276 7.00mm

Technical

Current - Saturation 34A
Inductance Frequency - Test 100kHz
Max DC Current 37A
DC Resistance (DCR) 2.5mOhm Max
Test Frequency 100kHz
Inductance 2.2μH
Current Rating 37A
Depth 16.85mm
Shielding Shielded
Current Rating (Amps) 37A
Composition Wirewound
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.677Lx0.663W 17.20mmx16.85mm
Series HCM1707
Published 2014
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C

Physical

Material - Core Iron Powder
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 8 Weeks
