FP2-D047-R
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FLAT-PAC Nonstandard 0.283Lx0.264W 7.20mmx6.70mm 47nH
PDF
/
Inventory: 1806
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 6.7mm
Length 7.1882mm
Height Seated (Max) 0.118 3.00mm
Height 3mm
Technical
Series Resistance 260μOhm
Current - Saturation 42A
Inductance Frequency - Test 1MHz
Max DC Current 42A
DC Resistance (DCR) 0.26mOhm
Test Frequency 1MHz
Inductance 47nH
Current Rating 37A
Depth 6.7mm
Shielding Unshielded
Current Rating (Amps) 37A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±15%
Size / Dimension 0.283Lx0.264W 7.20mmx6.70mm
Series FLAT-PAC
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Weight 907.18474mg
Number of Pins 4
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 25 Weeks
