100-470N
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR RoHS Compliant Radial Contains Lead fixed air core inductor 105C 250MHz 120mOhm 47nH
PDF
/
Inventory: 3475
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Free Hanging
Package / Case Nonstandard
Terminal Shape FLAT
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Packaging Bulk
Published 2002
Tolerance 30%
JESD-609 Code e0
Pbfree Code no
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Max Operating Temperature 105°C
Min Operating Temperature -55°C
HTS Code 8504.50.80.00
Shielding Unshielded
Number of Functions 1
Depth 2.79mm
Construction Rectangular
Current Rating 360mA
Lead Pitch 2.41mm
Lead Length 5.33mm
Inductance 47 nH
Test Frequency 50MHz
Max DC Current 360mA
Frequency - Self Resonant 250MHz
Inductor Application RF INDUCTOR
Lead/Base Style Radial
Quality Factor-Min (at L-nom) 40
Inductor Type GENERAL PURPOSE INDUCTOR
Q Factor 40
DC Resistance (DCR) - Parallel 120mOhm
Inductance-Nom (L) 0.047 μH
Dimensions
Height 1.65mm
Height Seated (Max) 1.651mm
Length 2.54mm
Width 2.54mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Contains Lead
