DR1050-390-R image
Favorite
DR1050-390-R image
Favorite
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description DR1050 Nonstandard 0.413Lx0.406W 10.50mmx10.30mm 39muH
PDF
/
Buying Options
Total Price: USD $0.86
Unit Price: USD $0.858637
≥1 USD $0.858637
≥200 USD $0.332164
≥500 USD $0.320348
≥1000 USD $0.315096
Inventory: 8511
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Weight 5.000005g
Material - Core Ferrite

Technical

Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2016
Series DR1050
Size / Dimension 0.413Lx0.406W 10.50mmx10.30mm
Tolerance ±30%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 2.35A
Shielding Shielded
Depth 10.3mm
Current Rating 2.35A
Inductance 39μH
Test Frequency 100kHz
DC Resistance (DCR) 75.9mOhm Max
Max DC Current 2.35A
Inductance Frequency - Test 100kHz
Current - Saturation 2.35A

Dimensions

Height 5mm
Height Seated (Max) 0.197 5.00mm
Length 10.4902mm
Width 10.287mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
