CD1-820-R
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Wirewound Obsolete 2007 Tape & Reel (TR) fixed air core inductor -40C~85C 100kHz 256mOhm Max 82muH
PDF
/
Inventory: 2053
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Dimensions
Height Seated (Max) 0.157 4.00mm
Technical
Current - Saturation 1.45A
Inductance Frequency - Test 100kHz
DC Resistance (DCR) 256mOhm Max
Inductance 82μH
Shielding Shielded
Current Rating (Amps) 1.5A
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Tolerance ±30%
Size / Dimension 0.413Lx0.409W 10.50mmx10.40mm
Series CD
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Material - Core Ferrite
Package / Case Nonstandard
Mounting Type Surface Mount
Alternative Model
