CMLS136E-100MS

Delta Electronics/Cyntec
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description ROHS3Compliant Active Tape & Reel (TR) Metal fixed air core inductor -55C~125C 100kHz 18.5mOhm Max 10muH
PDF
/
Buying Options
Total Price: USD $1.9
Unit Price: USD $1.9008
≥1 USD $1.9008
≥10 USD $1.61832
≥100 USD $1.491424
≥500 USD $1.332672
≥1000 USD $1.11056
≥3000 USD $1.07881
Inventory: 492
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 8 Weeks

Physical

Mounting Type Surface Mount
Package / Case Nonstandard
Material - Core Metal

Technical

Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series CMLS136E
Size / Dimension 0.530Lx0.496W 13.45mmx12.60mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Current Rating (Amps) 11A
Shielding Shielded
Inductance 10μH
DC Resistance (DCR) 18.5mOhm Max
Inductance Frequency - Test 100kHz
Current - Saturation 18A

Dimensions

Height Seated (Max) 0.256 6.50mm

Compliance

RoHS Status ROHS3 Compliant
