CMLB104T-R47MS
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Active Tape & Reel (TR) Metal fixed air core inductor -55C~125C 100kHz 1.5mOhm Max 470nH
PDF
/
Buying Options
Total Price: USD $1.36
Unit Price: USD $1.364
≥1 USD $1.364
≥10 USD $1.15632
≥100 USD $1.065152
≥500 USD $0.951984
≥1000 USD $0.793232
≥3000 USD $0.770598
Inventory: 672
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Surface Mount
Package / Case Nonstandard
Material - Core Metal
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series CMLB104T
Size / Dimension 0.439Lx0.394W 11.15mmx10.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Current Rating (Amps) 32A
Shielding Shielded
Inductance 470nH
DC Resistance (DCR) 1.5mOhm Max
Inductance Frequency - Test 100kHz
Current - Saturation 40A
Dimensions
Height Seated (Max) 0.157 4.00mm
Compliance
RoHS Status ROHS3 Compliant
