CMLB104T-3R3MS
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Active Tape & Reel (TR) Metal Fixed Inductor -55C~125C 100kHz 12mOhm Max 3.3muH
PDF
/
Buying Options
Total Price: USD $1.36
Unit Price: USD $1.364
≥1 USD $1.364
≥10 USD $1.15632
≥100 USD $1.065152
≥500 USD $0.951984
≥1000 USD $0.793232
≥3000 USD $0.770598
Inventory: 932
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.157 4.00mm
Technical
Current - Saturation 13.5A
Inductance Frequency - Test 100kHz
DC Resistance (DCR) 12mOhm Max
Inductance 3.3μH
Shielding Shielded
Current Rating (Amps) 10A
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.427Lx0.394W 10.85mmx10.00mm
Series CMLB104T
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Material - Core Metal
Package / Case Nonstandard
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
