SRN5040TA-3R3M
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
SRN5040TA Nonstandard 0.195Lx0.195W 4.95mmx4.95mm 3.3muH
PDF
/
Buying Options
Total Price: USD $0.44
Unit Price: USD $0.44
≥1 USD $0.44
≥10 USD $0.37664
≥100 USD $0.345312
≥500 USD $0.313984
≥1000 USD $0.2794
≥3000 USD $0.263718
Inventory: 1137
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mounting Type Surface Mount
Package / Case Nonstandard
Material - Core Ferrite
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series SRN5040TA
Size / Dimension 0.195Lx0.195W 4.95mmx4.95mm
Tolerance ±20%
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Terminal Finish Tin (Sn)
Current Rating (Amps) 3.5A
Shielding Semi-Shielded
Inductance 3.3μH
DC Resistance (DCR) 24mOhm
Frequency - Self Resonant 48MHz
Q @ Freq 15 @ 100kHz
Inductance Frequency - Test 100kHz
Current - Saturation 4.4A
Dimensions
Height Seated (Max) 0.161 4.10mm
Compliance
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
