RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR ROHS3Compliant Active 8504.50.80.00 fixed air core inductor -40C~125C 100kHz 0.245mOhm 500nH
PDF
/
Buying Options
Total Price: USD $2.41
Unit Price: USD $2.409172
≥1 USD $2.409172
≥200 USD $0.962356
≥500 USD $0.929533
≥1000 USD $0.913778
Inventory: 9217
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height Seated (Max) 0.295 7.50mm

Technical

Current - Saturation 17A
Inductor Type GENERAL PURPOSE INDUCTOR
Inductance Frequency - Test 100kHz
DC Resistance (DCR) 0.245mOhm
Inductance 500nH
Shielding Unshielded
Current Rating (Amps) 52A
HTS Code 8504.50.80.00
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±15%
Size / Dimension 0.433Lx0.283W 11.00mmx7.20mm
Series HCB1175
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C

Physical

Package / Case Nonstandard
Mounting Type Surface Mount
