0402HS-820EKTS
RoHS
RoHS compliant
RoHS compliantPackage 0402 (1005 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
0402HS 0402 (1005Metric) 0.050Lx0.030W 1.27mmx0.76mm 82nH
PDF
/
Buying Options
Total Price: USD $0.2
Unit Price: USD $0.2024
≥1 USD $0.2024
Inventory: 1173
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Surface Mount
Package / Case 0402 (1005 Metric)
Surface Mount YES
Terminal Shape WRAPAROUND
Material - Core Ceramic
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series 0402HS
Size / Dimension 0.050Lx0.030W 1.27mmx0.76mm
Tolerance ±10%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Wirewound
HTS Code 8504.50.80.00
Current Rating (Amps) 50mA
Shielding Unshielded
Number of Functions 1
Inductance 82nH
Test Frequency 250MHz
DC Resistance (DCR) 1.55Ohm
Frequency - Self Resonant 1.26GHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Q @ Freq 22 @ 250MHz
Quality Factor-Min (at L-nom) 22
Inductance Frequency - Test 250MHz
Rated Current-Max 0.05A
Dimensions
Height Seated (Max) 0.024 0.60mm
Compliance
RoHS Status ROHS3 Compliant
