CTX20-1-52M
RoHS
/
Package /
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR Non-RoHS Compliant PRINTED WIRING PIN DUAL IN-LINE fixed air core inductor 75C 0.1MHz 0.0829Ohm 20.22μH
PDF
/
Inventory: 3265
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Surface Mount NO
Terminal Shape PRINTED WIRING PIN
Shape/Size Description RECTANGULAR PACKAGE
Core Material IRON
Technical
Series CTX(HEADER)
Tolerance 20%
Number of Terminations 4
ECCN Code EAR99
HTS Code 8504.50.80.00
Packing Method Bulk
Shielding NO
Number of Functions 1
Construction Toroidal
Operating Temperature (Max) 75°C
Operating Temperature (Min) -40°C
Lead Length 3.8mm
Lead Spacing 6.5mm
Lead Diameter 0.5 mm
Test Frequency 0.1MHz
DC Resistance (DCR) 0.0829Ohm
Inductor Application POWER INDUCTOR
Terminal Placement DUAL IN-LINE
Inductor Type GENERAL PURPOSE INDUCTOR
Case/Size Code 3737
Rated Current-Max 1.8A
Inductance-Nom (L) 20.22 μH
Compliance
RoHS Status Non-RoHS Compliant
