SWC-3.0-47
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical (Open)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FIXED IND 47UH 3A 50 MOHM TH
PDF
/
Inventory: 1810
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Vertical (Open)
Material - Core Iron Powder
Technical
Operating Temperature -40°C~125°C
Packaging Bulk
Series SW
Size / Dimension 0.650Lx0.449W 16.50mmx11.40mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Toroidal
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Current Rating (Amps) 3A
Shielding Unshielded
Current Rating 3A
Inductance 47μH
Test Frequency 10kHz
DC Resistance (DCR) 50mOhm Max
Inductance Frequency - Test 10kHz
Dimensions
Height 19.304mm
Height Seated (Max) 0.760 19.30mm
Length 16.51mm
Width 11.4046mm
Compliance
RoHS Status ROHS3 Compliant
