XPL2010-102MLC image
Favorite
XPL2010-102MLC image
Favorite

XPL2010-102MLC

Coilcraft
RoHS
/
Package /
Category Inductors, Coils, Chokes / Fixed Inductors
Description 1muH 20% 20%
PDF
/
Buying Options
Total Price: USD $0.72
Unit Price: USD $0.71915
≥1 USD $0.71915
≥10 USD $0.58995
≥100 USD $0.5719
≥500 USD $0.55385
≥1000 USD $0.53485
Inventory: 1153
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status RoHS Compliant
REACH SVHC No SVHC

Dimensions

Width 2.1mm
Length 2.2mm
Height 1mm

Technical

RMS Current (Irms) 1.6A
Inductance-Nom (L) 1 μH
Inductance Tolerance 20%
DC Resistance (DCR) - Parallel 89mOhm
Case/Size Code 0808
Current - Saturation 1.2A
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Frequency - Self Resonant 117MHz
Max DC Current 1.6A
Test Frequency 100kHz
Inductance 1 μH
Reference Standard AEC-Q200
Construction Rectangular
Number of Functions 1
Shielding Shielded
Packing Method TR, Embossed Plastic, 7 Inch
HTS Code 8504.50.80.00
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Silver/Copper -Matte Tin -with Nickel barrier
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Part Status Active
Pbfree Code yes
Tolerance 20%
Published 2004
Packaging Cut Tape

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Composite
Terminal Shape ONE SURFACE
Mount Surface Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 9 hours ago)
