RFS1317-105KL
RoHS
/
Package /
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR Non-RoHS Compliant Contains Lead WIRE fixed air core inductor 85C 0.725MHz 1.02Ohm 1mH
PDF
/
Buying Options
Total Price: USD $2.06
Unit Price: USD $2.063966
≥1 USD $2.063966
≥10 USD $1.947136
≥100 USD $1.836922
≥500 USD $1.732944
≥1000 USD $1.634857
Inventory: 1081
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Self Resonant Frequency 0.725MHz
Inductance-Nom (L) 1000 μH
Inductance Tolerance 10%
Rated Current-Max 0.97A
Case/Size Code 6352
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement RADIAL
Inductor Application POWER INDUCTOR
DC Resistance (DCR) 1.02Ohm
Inductance 1 mH
Lead Diameter 0.8 mm
Lead Length 4.8mm
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Reference Standard AEC-Q200
Construction Cylindrical
Number of Functions 1
Shielding YES
Packing Method Tray
HTS Code 8504.50.80.00
Terminal Finish Tin/Silver (Sn/Ag) - Matte Tin (Sn) - Copper (Cu)
ECCN Code EAR99
Number of Terminations 2
Pbfree Code yes
Physical
Core Material Ferrite
Shape/Size Description CYLINDRICAL PACKAGE
Terminal Shape WIRE
Surface Mount NO
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 hours ago)
