LPS3015-182MLB

Coilcraft
RoHS
/
Package SMD/SMT
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR RoHS Compliant Contains Lead ONE SURFACE Fixed Inductor 85C 135MHz 100mOhm 1.8muH
PDF
/
Inventory: 3707
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Package / Case SMD/SMT
Surface Mount YES
Terminal Shape ONE SURFACE
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE

Technical

Packaging Cut Tape
Tolerance 20%
Pbfree Code yes
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Silver/Palladium/Platinum - with Glass frit
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8504.50.80.00
Packing Method TR
Shielding Shielded
Number of Functions 1
Reference Standard AEC-Q200
Inductance 1.8 μH
Test Frequency 100kHz
Max DC Current 1.4A
Frequency - Self Resonant 135MHz
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 1.5A
Case/Size Code 1212
DC Resistance (DCR) - Parallel 100mOhm
Inductance Tolerance 20%
Inductance-Nom (L) 1.8 μH
RMS Current (Irms) 1.4A

Dimensions

Height 1.5mm
Length 3.15mm
Width 3.15mm

Compliance

REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Contains Lead
