0805CS-330XJLC

Coilcraft
RoHS
/
Package 0805
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR RoHS Compliant Active Contains Lead Fixed Inductor 125C 2.15GHz 270mOhm 33nH
PDF
/
Buying Options
Total Price: USD $0.28
Unit Price: USD $0.27645
≥1 USD $0.27645
≥10 USD $0.22705
≥100 USD $0.2204
≥500 USD $0.2128
≥1000 USD $0.20615
Inventory: 1281
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status RoHS Compliant

Dimensions

Width 1.73mm
Length 2.29mm
Height 1.52mm

Technical

Special Feature Q IS MEASURED AT 500 MHZ
Inductance-Nom (L) 0.033 μH
DC Resistance (DCR) - Parallel 270mOhm
Q Factor 60
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 60
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 2.15GHz
Max DC Current 500mA
Test Frequency 250MHz
Inductance 33 nH
Reference Standard AEC-Q200
Construction Rectangular
Number of Functions 1
Shielding NO
Packing Method TR, Embossed Plastic, 7 Inch
HTS Code 8504.50.80.00
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Silver/Palladium/Platinum - with Glass frit
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Part Status Active
Pbfree Code yes
Tolerance 5%
Published 2009

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ceramic
Weight 5.499807mg
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case 0805
