0805AF-103XJRC
RoHS
/
Package 0805
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR RoHS Compliant Contains Lead WRAPAROUND fixed air core inductor 85C 26MHz 2.2Ohm 10muH
PDF
/
Buying Options
Total Price: USD $1.03
Unit Price: USD $1.027353
≥1 USD $1.027353
≥10 USD $0.969203
≥100 USD $0.914344
≥500 USD $0.862584
≥1000 USD $0.813763
Inventory: 924
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 hour ago)
Physical
Package / Case 0805
Surface Mount YES
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Tolerance 5%
JESD-609 Code e3
Pbfree Code yes
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8504.50.80.00
Packing Method TR, 7 Inch
Shielding NO
Number of Functions 1
Construction Chip
Inductance 10 μH
Test Frequency 2.5MHz
Max DC Current 230mA
Frequency - Self Resonant 26MHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Quality Factor-Min (at L-nom) 18
Inductor Type GENERAL PURPOSE INDUCTOR
Q Factor 18
Case/Size Code 0907
DC Resistance (DCR) - Parallel 2.2Ohm
Inductance-Nom (L) 10 μH
Dimensions
Height 1.52mm
Length 2.29mm
Width 1.73mm
Compliance
RoHS Status RoHS Compliant
Lead Free Contains Lead
