0603LS-182XJLB

Coilcraft
RoHS
/
Package 0603
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR RoHS Compliant Contains Lead WRAPAROUND Fixed Inductor 85C 80MHz 1.1Ohm 1.8muH
PDF
/
Inventory: 1571
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status RoHS Compliant
REACH SVHC No SVHC

Dimensions

Width 1.169mm
Length 1.8mm
Height 1.12mm

Technical

Inductance-Nom (L) 1.8 μH
Inductance Tolerance 5%
DC Resistance (DCR) - Parallel 1.1Ohm
Case/Size Code 0705
Q Factor 15
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 15
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 80MHz
Max DC Current 350mA
Test Frequency 7.9MHz
Inductance 1.8 μH
Current Rating 350mA
Construction Rectangular
Number of Functions 1
Shielding NO
Packing Method TR
HTS Code 8504.50.80.00
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Silver/Palladium/Platinum - with Glass frit
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Pbfree Code yes
Tolerance 5%
Packaging Cut Tape

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ceramic, Ferrite
Weight 2.012816mg
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case 0603

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 2 hours ago)
