BKPB002520122R2MA2
RoHS
RoHS compliant
RoHS compliantPackage 1008 (2520 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
BKPB 1008 (2520Metric) 0.098Lx0.079W 2.50mmx2.00mm 2.2muH
PDF
/
Buying Options
Total Price: USD $0.2
Unit Price: USD $0.197788
≥1 USD $0.197788
≥200 USD $0.078918
≥500 USD $0.076279
≥1000 USD $0.07498
Inventory: 1433
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.047 1.20mm
Technical
Special Feature DCR MEASURED AT 30% TOLERANCE
Rated Current-Max 1.2A
Current - Saturation 700mA
Inductance Frequency - Test 3MHz
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
DC Resistance (DCR) 100mOhm Max
Test Frequency 3MHz
Inductance 2.2μH
Number of Functions 1
Shielding Shielded
Current Rating (Amps) 1.2A
Type Multilayer
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.098Lx0.079W 2.50mmx2.00mm
Series BKPB
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case 1008 (2520 Metric)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
