SRR0603-331K
RoHS
/
Package 0603
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR Copper Non-RoHS Compliant WRAPAROUND fixed air core inductor 125C 4.5MHz 4.2Ohm 330muH
PDF
/
Inventory: 908
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 6.5mm
Length 6.5mm
Height 3.3mm
Technical
Special Feature Q MEASURED AT 0.796 MHZ
Inductance-Nom (L) 330 μH
DC Resistance (DCR) - Parallel 4.2Ohm
Case/Size Code 2626
Q Factor 18
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 18
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Frequency - Self Resonant 4.5MHz
Max DC Current 180mA
Test Frequency 0.796MHz
Inductance 330 μH
Number of Functions 1
Shielding Shielded
Packing Method TR
HTS Code 8504.50.80.00
Max Operating Temperature 125°C
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Tolerance 10%
Physical
Core Material FERRITE
Conductor Material Copper
Shape/Size Description RECTANGULAR PACKAGE
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case 0603
