SRP7030-R56FM
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
SRP7030F Nonstandard 0.299Lx0.256W 7.60mmx6.50mm 560nH
PDF
/
Buying Options
Total Price: USD $7.4
Unit Price: USD $7.3967
≥1 USD $7.3967
≥10 USD $6.06955
≥100 USD $5.87955
≥500 USD $5.68955
≥1000 USD $5.5005
Inventory: 1655
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.118 3.00mm
Height 3mm
Technical
DC Current 15A
Inductance Tolerance 20%
Case/Size Code 7070-30M
Current - Saturation 17A
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Max DC Current 15A
DC Resistance (DCR) 5mOhm Max
Test Frequency 100kHz
Inductance 560nH
Military Standard Not
Base Part Number SRP7030
Current Rating 15A
Depth 6.7mm
Number of Functions 1
Shielding YES
Packing Method TR, 13 Inch
HTS Code 8504.50.80.00
Composition Wirewound
Terminal Finish Copper/Tin (Cu/Sn)
Type Molded
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e2
Tolerance ±20%
Size / Dimension 0.299Lx0.256W 7.60mmx6.50mm
Series SRP7030F
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Iron
Number of Pins 2
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
