SRP7030-R33FM
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
SRP7030F Nonstandard 0.299Lx0.256W 7.60mmx6.50mm 330nH
PDF
/
Inventory: 6547
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Inductance 330nH
Test Frequency 100kHz
DC Resistance (DCR) 3.4mOhm Max
Max DC Current 18A
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Current - Saturation 25A
Case/Size Code 7070-30M
Inductance Tolerance 20%
DC Current 18A
RMS Current (Irms) 18A
Military Standard Not
Base Part Number SRP7030
Current Rating 18A
Depth 6.7mm
Number of Functions 1
Shielding YES
Packing Method TR, 13 Inch
HTS Code 8504.50.80.00
Composition Wirewound
Terminal Finish Copper/Tin (Cu/Sn)
Type Molded
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e2
Tolerance ±20%
Size / Dimension 0.299Lx0.256W 7.60mmx6.50mm
Series SRP7030F
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Dimensions
Height 3mm
Height Seated (Max) 0.118 3.00mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Iron
Number of Pins 2
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 18 Weeks
