SRP5030TA-R22M
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
RoHS Compliant Wirewound Active WRAPAROUND fixed air core inductor -40C~150C 155MHz 4.4mOhm Max 220nH
PDF
/
Buying Options
Total Price: USD $0.73
Unit Price: USD $0.72866
≥1 USD $0.72866
≥200 USD $0.282274
≥500 USD $0.27177
≥1000 USD $0.267832
Inventory: 9372
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.118 3.00mm
Technical
Rated Current-Max 15.5A
Case/Size Code 2120
Current - Saturation 21A
Inductance Frequency - Test 100kHz
Quality Factor-Min (at L-nom) 5
Q @ Freq 5 @ 100kHz
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Frequency - Self Resonant 155MHz
DC Resistance (DCR) 4.4mOhm Max
Test Frequency 0.1MHz
Inductance 220nH
Reach Compliance Code compliant
Number of Functions 1
Shielding Shielded
Packing Method TR, EMBOSSED, 13 INCH
Current Rating (Amps) 15.5A
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
Type Wirewound
ECCN Code EAR99
Number of Terminations 2
Part Status Active
JESD-609 Code e3
Tolerance ±20%
Size / Dimension 0.224Lx0.205W 5.70mmx5.20mm
Series SRP5030TA
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Carbonyl Powder
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case Nonstandard
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 18 Weeks
