SRP1040-330M image
Favorite
SRP1040-330M image
Favorite

SRP1040-330M

Bourns Inc.
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description SRP1040 Nonstandard 0.465Lx0.413W 11.80mmx10.50mm 33muH
PDF
/
Inventory: 1646
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height Seated (Max) 0.165 4.20mm
Height 4.191mm

Technical

Inductance Tolerance 20%
Current - Saturation 5A
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Max DC Current 3A
DC Resistance (DCR) 87mOhm Max
Test Frequency 100kHz
Inductance 33μH
Current Rating 3A
Reach Compliance Code unknown
Depth 10mm
Number of Functions 1
Shielding YES
Packing Method TR, 13 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Tolerance ±20%
Size / Dimension 0.465Lx0.413W 11.80mmx10.50mm
Series SRP1040
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Iron
Number of Pins 2
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
