SRN4018-331M
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Wirewound Active 8504.50.80.00 fixed air core inductor -40C~125C 6MHz 6.36Ohm Max 330muH
PDF
/
Buying Options
Total Price: USD $0.37
Unit Price: USD $0.3696
≥1 USD $0.3696
≥10 USD $0.31856
≥100 USD $0.29216
≥500 USD $0.265584
≥1000 USD $0.23628
≥3000 USD $0.223027
Inventory: 1142
Minimum: 1
-
+
Technical Details
Technical
Terminal Finish Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5)
HTS Code 8504.50.80.00
Type Wirewound
ECCN Code EAR99
Part Status Active
JESD-609 Code e1
Tolerance ±20%
Size / Dimension 0.157Lx0.157W 4.00mmx4.00mm
Series SRN4018
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Current - Saturation 210mA
Inductance Frequency - Test 100kHz
Q @ Freq 30 @ 796kHz
Frequency - Self Resonant 6MHz
DC Resistance (DCR) 6.36Ohm Max
Inductance 330μH
Shielding Semi-Shielded
Current Rating (Amps) 200mA
Physical
Material - Core Ferrite
Package / Case Nonstandard
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 18 Weeks
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Height Seated (Max) 0.071 1.80mm
